Name: ALUDONG PVDF ALUMINUM COMPOSITE PANEL FOR EXTERIOR FACADE
Brand: Henan Jixiang Industrial Co., Ltd
SKU: ALD-8801
Price: 8.00 USD
Availability: InStock

Para casa > produtos > Painel composto de alumínio de PVDF >

ALUDONG PVDF ALUMINUM COMPOSITE PANEL FOR EXTERIOR FACADE

PVDF aluminum composite panel exterior facade

aluminum composite panel for building facade

PVDF coated ACP exterior cladding

Lugar de origem:

CHINA

Marca:

ALUDONG

Certificação:

CE，SGS，ISO

Número do modelo:

ALD-8801

Contacte-nos

Solicite um orçamento

Detalhes do produto

Tratamento de superfície:

Lustroso

Uso:

Interno, ao ar livre

Cor:

Requisitos do cliente

Tamanho:

1220*2440,1.22*2.44m, personalizou

Espessura do painel:

4mm

Espessura do Alumínio:

0,3 mm

Tamanho padrão:

1220*2440mm

Largura:

1220MM, 1500MM

Revestimento:

PVDF

Comprimento:

2440mm (de acordo com o pedido dos clientes)

Material principal:

Polietileno

Material:

Alumínio

Espessura do alumínio:

0,2 mm 0,3 mm 0,4 mm

Destacar:

PVDF aluminum composite panel exterior facade

aluminum composite panel for building facade

PVDF coated ACP exterior cladding

Termos de pagamento e envio

Quantidade de ordem mínima

600m2

Preço

7-10 USD/SQM

Detalhes da embalagem

embalagens nuas ou paletes de madeira

Tempo de entrega

10-15 dias

Termos de pagamento

T/T,L/C

Habilidade da fonte

1000000 folhas por mês

Produtos relacionados

Vídeo

Painéis compostos de alumínio revestidos com PVDF de 4 mm resistentes às intempéries para revestimento de parede de cortina exterior

Obtenha o melhor preço

Vídeo

Amostragem gratuita disponível Folha de alumínio composta ACP/ACM impressa sob medida de 4 mm Sem pedido de ensaio de risco

Obtenha o melhor preço

Vídeo

Folha de plástico de alumínio revestida com PE de 3 mm e 4 mm ACP/ACM para decoração de parede interior de banheira de cozinha

Obtenha o melhor preço

Painel composto de alumínio revestido de PVDF de 4 mm para revestimento de parede externa

Obtenha o melhor preço

Contacte-nos

86-15238626739

jasonlee@henanjixiang.com

86-371-60292098

Contacte agora

Descrição do produto

Company Profile

HENAN JIXIANG INDUSTRY CO.,LTD

HENAN JIXIANG INDUSTRY CO.,LTD is a leading Chinese manufacturer of aluminum and composite materials with over 20 years of expertise. Certified with ISO 9001, CE, and SGS, we export to 100+ countries, offering reliable materials by R&D innovation and strict quality control.

ALUDONG ALUMINUM COMPOSITE PANEL

Henan Jixiang Industry Co., Ltd; Henan Aludong Decorative Materials Co.,Ltd is located in Zhengzhou City,Henan Province, Which a professional enterprise manufacturing high and new-tech aluminum composite products,which is one of the earliest and scaled manufacturers of aluminum composite, coated aluminum coils, aluminum solid panel in China.Our company possesses16 production lines and 6 coating lines for aluminum composite panels whose annual output is 5800000 square meters.In addition, our company has passed ISO9001 International Quality Management System Certification, ISO14000 Environment Management System Certification, OHSAS18000 Occupation Health Safety Management System Certification, and CTC Product Quality Certification, and won several national patents.

Specification

DIMENSIONAL STANDARD:

Standard Size: 1220*2440mm

Optional width: 1000/1020/1050/1250/1500/1550/1570mm

Optinal lenghth: as requests

Standard Thickness: 3/4mm

Optinal Thickness: 2/2.5/5/6/7/8mm

Dimensional Tolerance:

Panel width: +-2mm

Panel length: +-3mm

Panel thickness: +-0.2mm

Panel diagonal: <5mm

Aluminum sheet thickness: +-0.02mm

ALUDONG ACP APPLICATION:

•Outdoor advertising

•Signage
•Store Poster
•Supermarket poster
•Decorative mural painting
•Exhibition
•Partition
•Outdoor signage - Company sign boards, small pylons,wall advertising •board
•Exhibition stands / wall panels / ceiling construction
•POS applications
•Retail interior furnishings
•Digital Printing
•The product colour could be changed by vinyl application / spray paint

SOLID & METALLIC

WOODEN & MARBLE

BRUSHED

ALUDONG ACP Characteristics

Products features:

•Light weight•Excellent curve and bend strength
•Choice of rich colors and finishes
•Flat surface and consistent colors
•Easy processing and installation
•Fine impact resistance
•Exceptional weather resistance
•Easy maintenance
•Fire reistanct
•Printable surface as sign materials

•Customized size avaliable

Specifications

(Custom configurations available upon request.)

WIDTH	PE	PVDF	ANODIZED MIRROR
1000-1220mm	0.05-0.50mm	0.21-0.50mm	0.30-0.50
1500-1570mm	0.15-0.50mm	0.21-0.50mm	/

ALUDONG PVDF ALUMINUM COMPOSITE PANEL

TECHNICAL DATA

Description	Test standard	PVDF
Coating Thickness (μm)	Polyester paint >=25μm	26μm
Coating flexibility (T-bend)	Polyester paint ≤ 3T	≤ 2T
Color different	ΔE<=2.0 (follow color sample)	ΔE<=2.0
Pencil hardness	>=HB	>=2H
Chemical resistance	5%HCI or 5%NaOH test in 48 hours -No change	No change
Coating adhesion	>=1grade for 10810mm2 gridding test	1grade
Resist solvent	100 times without change	No change
Boiling water resistance	2 hours without change	No change
Peeling strength/stripping strength	Average >=5N/mm of 180oc peel off for panel with 0.30mm alu.skin	5N/mm
Impact test for paint	50KG.cm impact-paint no split for panel	No split
Abrasion resistance (L/Mi)	NIL	NIL
Temperature resistance	-40ºC to +80ºC temperature without change of color differenceand paint peel off , peeling strength average dropprate<=10%	Change of glossy only, no paint Peel off
Coefficient of linear Thermal Expansion	100ºC temperature difference	2.4mm/n
Detergent resistance (3%)	ASTM D2248	No change
Humidity Resistance	ASTM D2247 (3000hrs,100%RH,100°F)	No change
Salt spray resistance	ASTM B117 (3000hrs,5% salt)	No change
Resistance to Staining	600h radiate in 800W/M2 in humidity condition,glossiness deviation less grade 2,color difference <=4.0	No change

After Sales Service

Standard Warranty: 10 days for outter looks after upload goods, 6 months for inner quality
Extended Warranty: Optional coverage up to 24 months.
Global Support: 24/7 technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.

Why Choose Us?

Other Products

OEM/ODM capabilities
Competitive pricing & bulk discounts
Fast shipping & customs clearance support

Project solutions

Large Produdction capacity

ZWM brand / ALUDONG brand

Aluminum Honeycomb Panel

Stainless Steel Composite Panel

Coated Aluminum Coils

Solid Aluminum Panel

FAQ

Q: What's the lead time for orders?
A: Standard models ship in 15–20days; customized units require 20–25days.

Q: Do you have waranty for the materials?
A: Yes, PE coat: 3-5 years; PVDF: 10-15 years for exterior.

Q: Do you provide after-sales service overseas?
A: Yes, we have partnered service centers in key regions.

Q: Can I request a customized size and brand?
A: Absolutely! We offer customized size and branded service.

Q: What documents do you provide for export?
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).

Q: How do I place an order?
A: Contact us via email/phone for a quote, then confirm with a PO.
